| Specification |
Phase I & II |
Phase III |
Phase IV |
Phase V * |
Typical Floor
Plate |
30,000 to 42,000 sq ft |
30,000 sq ft |
50,000 sq ft |
B9 - 42,000 sq ft
B10 - 30,000 sq ft
(can be combined) |
| Scalability |
15,000 to 500,000 sq ft |
10,000 to 400,000 sq ft |
25,000 to 400,000 sq ft |
20,000 to 1.14 million sq ft |
| Designed for Zone III seismic activity |
| Column Grid |
10.8m |
11 mtrs X 11.2 mtrs
(some grids are smaller) |
Similar to Phase III |
8.5 mtrs X 8.5 mtrs |
Floor to Floor
Height |
4.2m |
4.2m |
4.2m |
4.2m |
Floor Loading
Capacity |
General Floor 400 kg/sqm
Critical areas 1000 kg/sqm
(UPS and server rooms)
AHU Rooms 600 kg/sqm |
General Floor 400 kg/sqm
Critical areas 1000 kg/sqm
(UPS and server rooms)
AHU Rooms 600 kg/sqm |
General Floor 400 kg/sqm
Critical areas 1000 kg/sqm
(UPS and server rooms)
AHU Rooms 600 kg/sqm |
General Floor 400 kg/sqm
Critical areas 1000 kg/sqm
(UPS and server rooms)
AHU Rooms 600 kg/sqm |
Power
Capacity |
0.90 KVA per 100 sq ft
Carpet area exclusive of
A.C. chillers and pumps |
0.90 KVA per 100 sq ft
Carpet area exclusive of
A.C. chillers and pumps |
0.90 KVA per 100 sq ft
Carpet area exclusive of
A.C. chillers and pumps |
0.90 KVA per 100 sq ft
Carpet area exclusive of
A.C. chillers and pumps |
| Elevators |
6 Passenger &
2 Service lifts per block |
Out of the 8 passenger lifts, 4 are functional between the Ground and 8th floor; the
other 4 are functional between the Ground and balance upper floors (9-15)
2 Service lifts service all floors including basements |
8 Passenger &
2 Service lifts. |
Building B9
Out of the 16 passenger lifts, 8 will be functional between the Ground and 13th floor; the
other 8 will be functional between the Ground and balance upper floors (14-23)
2 Service lifts service all floors
2 Parking lifts from Basements to Ground
Building B10
5 Passenger &
2 Service lifts |
Water Storage
Facility |
Decentralised with adequate storage in underground and overhead tanks |
Decentralised with adequate storage in underground and overhead tanks |
Decentralised with adequate storage in underground and overhead tanks |
Decentralised with adequate storage in underground and overhead tanks |
| Signage |
In consultation with our signage consultants |
In consultation with our signage consultants |
In consultation with our signage consultants |
In consultation with our signage consultants |
>
